Test standard:
Outdoor waterproof testing equipment is designed according to the
relevant standard requirements of IEC60529:1989+A1:1999 IPX5/6.
Application:
IPX5 and IPX6 Rain Spray Test Apparatus simulates the water drip
environment to test the water resistance and sealing of the samples
during storage, transportation and usage. It is widely applied to
electrical and electronic products, lamps and lanterns, electrical
cabinet, electrical components, automobile, motorcycle and its
spare parts and other products. It provides the basis to improve
the performance of the products.
Features:
1. Split type structure, safe and reliable, equipment rack and
sample turntable all by the high quality aluminum alloy item No.
and SUS304# stainless steel plate, ensures a long time use does not
rust.
2. Turntable electrical part fully sealed to prevent water leakage,
turntable use speed motor, speed in the standard range can be
adjusted, and can control the forward and reverse rotation
(suitable for the sample with the electric test).
3. Comes with a water tank, the water tank installed with the water
level float valve automatically control the water, and there is a
low level alarm detection, effectively prevent the water pump dry
and turn damaged.
4. Electrical components used in all such as LG, Omron and other
imported brands, wiring craft accord with the requirements of the
national standard, panel layout is reasonable, firm connection and
marked clearly.
5. Test time can be set 0-999M adjustable, the sample power with
power time control function, IPX5 and IPX6 test a key conversion, a
key to start, automatic stop, simple intelligence.
6. Spray nozzle: according to the relevant standard requirements of
IEC60529
Technical parameters:
| Equipment parameters |
| Item No. | LX-IPX56A |
| Control system | (key type) time relay + switch |
| Exterior chamber size | W1026*D776*H1345 (mm) (Contain castor) |
| Water storage tank volume | 420L, Size700×500×1200(mm), SUS304 |
| IPX5 Spray nozzle diameter | 6.3mm |
| IPX6 Spray nozzle diameter | 12.5mm |
| IPX5 Water flow | 12.5±0.625 L/min |
| IPX6 Water flow | 100±5 L/min |
| Water pressure(Mpa) | adjustable |
| Water flow control | Valve for water flow regulation and shut off. |
| Space from nozzle to sample | 2.5m-3m |
| Fixed method of spray gun | Hand Held |
| Water pump | Stainless steel multistage pump |
| Waterway material | Stainless steel + PPR pipe welding |
| Rotary table size | ¢600 mm |
| Rotary table power supply | AC220V |
| Material | SUS304 |
| Protection device | Leakage, water shortage, short circuit |
| Power supply | 380V |
| Power requirements | 3 KW |
| According to | IEC60529:1989+A1:1999, GB4208, GB7000.(IPX5, IPX6) |
